OVERVIEW
• 2 Ch. microphone or instrument input
• Dual stereo headphone output
• Dual stereo monitor outputs
• Multi-Format Audio A/D, D/A and D/D Converter
• Up to 984 Input and Output Channels
• Router and Monitoring Interface
• Thunderbolt 3 I/O (256 Ch.)
• Dante AoIP I/O (256 Ch.)
• MADI I/O (64 to 192 Ch.)
• ADAT I/O (16 Ch.) / S/PDIF (2 ch.)
• 2 Slots for Optional Multi-Format DAD I/O Cards
• 512x64 Ch. Pro|Mon Summing and Speaker 1024 ch. EQ Processing


FEATURES
• 2 Thunderbolt 3 Ports (each w. 15W power)
• 256 Bidirectional Channels at 48 & 96 kHz, 128 channels at 192 kHz
and 64 channels at 384 kHz
• ASIO / Core Audio Thunderbolt PCIe Drivers
• MADI on BNC (64 ch.)
• ADAT / TosLink Lightpipes (16 Ch.), configurable as 2 Ch. S/PDIF input
• DANTE: 256 Ch. at 48 kHz, 128 Ch. at 96kHz, 64 Ch. at 192 kHz (IP Core)
• Module Slot for Optional 2 x SFP (LC Fiber or HD/BNC Coax) (2 x 64 ch.)
• Two card slots for optional DAD I/O Cards
• WC I/O, VBB in
• SPQ: 64 Ch. with 16 Filters
• Pro|Mon Support
• Summing Processor 64 Output / 512 Input Busses
• Internal Router: 4096 x 4096
• 32bit Floating Point Processing
• 8 Slots for Any Available Expansion Cards
• Avid Eucon Enabled Devices via DADman
• Apple Silicon M1 and Intel Compatible Software
• Control via Ethernet or Thunderbolt Connection
• 19” Rack Unit 1U Height



AUDIO DRIVER SUPPORT FOR macOS
• Core Audio Thunder|Core Audio Driver
• Compatible with Intel and Apple Silicon (M1) processors, as well as Big Sur macOS and forward
• Core Audio Aggregates for More Applications I/O Control Connection for DADman


AUDIO DRIVER SUPPORT FOR WINDOWS
• ASIO Thunder|Core Audio Driver
• Compatible with Windows 10 and forward
• One Application Can Connect to the Asio Driver
• Control Connection for DADman
